Further Vehicle Details
Specification:
Type ELECTRIC
Make NISSAN
Valves 3
Character.
Load Centre (c) 500-700 mm
Operating mode (Characteristic) Seated
Weights
Service weight (Total weight ) 5200 kg
Wheels
Tyres type Cushion
Tyres front condition 85%
Tyres rear condition 45%
Dimensions
Lift height (h3) 4360 mm
Extended height (h4) 5460 mm
Height of overhead guard (cabin) (h6) 2120 mm
Overall length (l1) 3600 mm
Length to fork face (l2) 2400 mm
Overall width (b1/b2) 1130 mm
Forks length (l) 1200 mm
Fork carriage (class) DIN 15173 / 3A
Fork carriage width (b3) 1020 mm
Collapsed height (h1) 1980/2120 mm
Forks height (s) 40 mm
Forks width (e) 100 mm
Auxiliary lift (h9) 1590 mm
Performance
Service brake hydraulic/mechanical
Drive
Battery voltage/capacity 72V / 525Ah V/Ah
Battery (Acc. to DIN) WB
Attachment
Attachments (Has attachment) Sideshift and Forks.
Attachment type (Attachment type) Sideshifts
Engine
Engine type (Engine type) electric
Extras
Extras SS, Lights.
Extras Hyds 3rd
Battery
Battery Serial No WN160616030
